Description
| Order no. | Nominal size mm | Product type | Nominal value of | Nominal Diameter up to | Measuring range | Manufacturing tolerance | Hysteresis fu (µm) | Repeatability fw (µm) |
| 4478200 |
3.991 – 8.000
|
844 Dk
|
3.991 mm
|
8 mm
|
0.1 mm
|
-0.02 / -0.04
|
0.4 µm
|
1 µm
|
| 4478201 |
8.001 – 16.000
|
844 Dk
|
8.001 mm
|
16 mm
|
0.15 mm
|
-0.02 / -0.04
|
0.4 µm
|
1 µm
|
| 4478202 |
16.001 – 25.000
|
844 Dk
|
16.001 mm
|
25 mm
|
0.2 mm
|
-0.02 / -0.05
|
0.4 µm
|
1 µm
|
| 4478204 |
25.001 – 32.000
|
844 Dk
|
25.001 mm
|
32 mm
|
0.2 mm
|
-0.02 / -0.05
|
0.4 µm
|
1 µm
|
| 4478205 |
32.001 – 44.000
|
844 Dk
|
32.001 mm
|
44 mm
|
0.2 mm
|
-0.02 / -0.06
|
0.4 µm
|
1 µm
|
| 4478206 |
44.001 – 50.000
|
844 Dk
|
44.001 mm
|
50 mm
|
0.2 mm
|
-0.03 / -0.06
|
0.4 µm
|
1 µm
|
| 4478207 |
50.001 – 60.000
|
844 Dk
|
50.001 mm
|
60 mm
|
0.2 mm
|
-0.03 / -0.06
|
0.4 µm
|
1 µm
|
| 4478208 |
60.001 – 70.000
|
844 Dk
|
60.001 mm
|
70 mm
|
0.2 mm
|
-0.03 / -0.06
|
0.4 µm
|
1 µm
|
| 4478209 |
70.001 – 80.000
|
844 Dk
|
70.001 mm
|
80 mm
|
0.2 mm
|
-0.04 / -0.07
|
0.4 µm
|
1 µm
|
| 4478210 |
80.001 – 90.000
|
844 Dk
|
80.001 mm
|
90 mm
|
0.2 mm
|
-0.04 / -0.07
|
0.4 µm
|
1 µm
|
| 4478211 |
90.001 – 100.000
|
844 Dk
|
90.001 mm
|
100 mm
|
0.2 mm
|
-0.04 / -0.07
|
0.4 µm
|
1 µm
|
| 4478212 |
100.001 – 110.000
|
844 Dk
|
100.001 mm
|
110 mm
|
0.2 mm
|
-0.04 / -0.07
|
0.4 µm
|
1 µm
|
| 4478213 |
110.001 – 120.000
|
844 Dk
|
110.001 mm
|
120 mm
|
0.2 mm
|
-0.04 / -0.07
|
0.4 µm
|
1 µm
|
| 4478214 |
120.001 – 130.000
|
844 Dk
|
120.001 mm
|
130 mm
|
0.2 mm
|
-0.04 / -0.07
|
0.4 µm
|
1 µm
|
| 4478215 |
130.001 – 140.000
|
844 Dk
|
130.001 mm
|
140 mm
|
0.2 mm
|
-0.04 / -0.07
|
0.4 µm
|
1 µm
|
| 4478216 |
140.001 – 150.000
|
844 Dk
|
140.001 mm
|
150 mm
|
0.2 mm
|
-0.04 / -0.07
|
0.4 µm
|
1 µm
|
| 4478217 |
150.001 – 160.000
|
844 Dk
|
150.001 mm
|
160 mm
|
0.2 mm
|
-0.04 / -0.07
|
0.4 µm
|
1 µm
|
| 4478218 |
160.001 – 170.000
|
844 Dk
|
160.001 mm
|
170 mm
|
0.2 mm
|
-0.04 / -0.07
|
0.4 µm
|
1 µm
|
| 4478219 |
170.001 – 180.000
|
844 Dk
|
170.001 mm
|
180 mm
|
0.2 mm
|
-0.04 / -0.07
|
0.4 µm
|
1 µm
|
| 4478220 |
180.001 – 190.000
|
844 Dk
|
180.001 mm
|
190 mm
|
0.2 mm
|
-0.04 / -0.07
|
0.4 µm
|
1 µm
|
| 4478221 |
190.001 – 200.000
|
844 Dk
|
190.001 mm
|
200 mm
|
0.2 mm
|
-0.04 / -0.07
|
0.4 µm
|
1 µm
|
| 4480184 |
2.980 – 3.990
|
844 Dk
|
2.98 mm
|
3.99 mm
|
0.1 mm
|
-0.02 / -0.04
|
0.4 µm
|
1 µm
|
